The Humboldt Forum (Berlin) installs an audio over IP infrastructure with Lawo

08/03/2021

The Humboldt Forum (Berlin) installs an audio over IP infrastructure with Lawo La instalaci n de Lawo en el famoso Palacio de Berl n en la Isla del Spree utiliza tres consolas de producci n Lawo mc 56 de ltima generaci n y once sistemas de E/S Dallis.

The Foro Humboldt, con sus museos, lugares para eventos, espacios para exposiciones e instalaciones para la educaci n cultural, se encuentra en el famoso Palacio de Berl n en la Isla del Spree, en el centro hist rico de Berl n.

Si bien sus fachadas son en gran medida calcadas a las originales, el interior del complejo est equipado con tecnolog a de ltima generaci n adaptada a las necesidades modernas, y suministrada por Lawo.

El integrador de sistemas Digitech ha instalado una infraestructura de audio de ltima generaci n basada en IP y conectada en red a trav s de una matriz Lawo Nova73 HD ubicada en el centro. Dise ada para ser flexible y escalable, la instalaci n de Lawo utiliza tres consolas de producci n Lawo mc 56 de ltima generaci n y once sistemas de E/S Dallis.

Todas las reas para eventos y proyectos de arte sonoro est n conectadas a trav s de stageboxes de Lawo, cada una de ellas equipada para satisfacer los requisitos de sus respectivas instalaciones. La transferencia de se ales en todo el edificio se realiza a trav s de la matriz central.

Las principales salas del Foro Humboldt est n ampliamente equipadas con tecnolog a de audio. Incluyen dos salas de eventos en vivo de 500 m y 461 m , el vest bulo principal y varias salas de seminarios. El patio Schl terhof, el pasaje y otras zonas se utilizan para eventos y actividades al aire libre y son alquiladas por grupos de inter s como la Stiftung Stadtmuseum (Fundaci n del Museo de la Ciudad), la Fundaci n del Foro Humboldt, los Staatliche Museen zu Berlin (Museos Estatales de Berl n) y la Universidad Humboldt de Berl n.

Cada una de las dos salas alberga una sala de control con una consola de mezclas mc 56 (MKIII) (una consola de 32 y 48 faders, respectivamente), as como una sala de equipamiento central com n cuyo panel de conexi n se conecta a las cajas de escenario generosamente distribuidas por las instalaciones para eventos y visitantes; stas est n y equipadas con interfaces para audio, v deo, tecnolog a de conferencias y control.

Archivo sonoro El Klangwerkstatt (Taller de sonido), gestionado por los Museos Nacionales de Berl n, se encarga de la importante labor de mantener el Lautarchiv, una colecci n de grabaciones sonoras hist ricas. Este famoso archivo, una de las primeras instituciones de este tipo en Europa, contiene una colecci n de alrededor de 7.500 discos de goma laca, cilindros de cera y cintas de audio con grabaciones hist ricas, algunas de las cuales tienen m s de 120 a os de antig edad, que ofrecen a los visitantes y a los investigadores una visi n fon tica y ling stica inestimable de la poca del Imperio Alem n y de la Rep blica de Weimar.

Adem s de las instalaciones t cnicas para la restauraci n de fuentes ac sticas, el taller de sonido cuenta con un estudio de grabaci n centrado en una tercera consola Lawo mc 56 equipada con 48 faders, que ofrece hasta 600 canales DSP de emisi n totalmente equipados y una capacidad de enrutamiento de hasta 5120 5120 canales mono. La sala de control y la conectividad de audio permiten integrar y utilizar toda la casa para proyectos hist ricos y art sticos.

Birger Gross, Jefe de Ingenier a de Audio y V deo del Foro Humboldt, comenta que la amplia gama de eventos que se esperan en el futuro, tanto en t rminos de espacio como de car cter art stico-t cnico, y los enlaces de red entre ellos, inclinaron la balanza a favor del sistema de Lawo. La consola de producci n mc 56 de Lawo, establecida y reconocida principalmente en el sector del broadcast y ahora tambi n en grandes y peque os teatros y teatros de pera, punt a en varios campos. Adem s de su rendimiento y flexibilidad, ofrece un trabajo intuitivo en la propia superficie -incluyendo el manejo de DSP y las funciones de medici n y monitorizaci n, as como la capacidad remota a trav s de la mxGUI- y su capacidad de conexi n, a trav s del control Crestron por ejemplo, permite conducir y controlar eventos m s sencillos pr cticamente sin personal especializado .

Los once bastidores Dallis est n distribuidos por todo el edificio e instalados en las respectivas sedes, por lo que los recorridos de la se al hasta las fuentes de los micr fonos se mantienen agradablemente cortos. Como operadores t cnicos, nos alegramos de que las se ales de las distintas sedes tambi n est n disponibles para todas las dem s consolas a trav s del router, y la seguridad de la emisi n se mantiene mediante el sistema de derechos configurado. Este intercambio mutuo de se ales entre todas las sedes, respaldado por la propia redundancia de Lawo, aumenta enormemente las posibilidades creativas , a ade Gross.

Adem s del sistema de sonido principal de Kling&Freitag, la Sala 2 est equipada con un sistema de reverberaci n Vivace con 62 altavoces independientes en las paredes y el techo, y la Sala 1 con doce altavoces de pared adicionales. Esta variabilidad, concretamente el gran n mero de altavoces adicionales que pueden ser controlados directamente por el sistema Lawo, tambi n ser utilizada por Instrument, una plataforma de composici n basada en IA. sta accede al archivo sonoro y lo compone evaluando par metros etnol gicos, geogr ficos y te ricos de la m sica. A medida que se desarrolle este instrumento, tambi n incluir grabaciones en directo del p blico, lo que le permitir reaccionar de forma muy espont nea para incluir eventos sonoros de llamada y respuesta en toda la casa.
LINK: https://www.panoramaaudiovisual.com/en/2021/03/04/humboldt-berlin-audi...
